Over 90T Truck crane
≥100 T
Max. Lifting Capacity
≥56 m
Max. Boom Length
≥77.5 m
Max. Lifting Height
Features
Cost Efficiency
Large lifting capacity crane mounted on robust chassis. Some models feature all wheel steering.
Smart Hydraulics
A more significant flow ensures higher efficiency, such as the higher speed of wire rope reeling. A shunted mode of independently controlled combined motions, like simultaneous vibration-free luffing and hoisting, realizes higher stability.
Double Pump Intelligent Flow Distribution System
The electro-hydraulic control system realizes effective flow distribution, featuring quick response to combined motions and small impact shock, energy saving, and environmentally friendly. Precise control: Excellent inching performance, min. The stable speed of a single rope is 1.2m/min and min. The sound speed of slewing is 0.1°/s, realizing precise lifting of mm level. Integrated slewing buffer control: boost buffer, sequential brake, and free swing technology—smooth start and stop.
High-performance Chassis
Innovative structural frame verified by 200,000 cycling fatigue tests to ensure high reliability.
Specs & Compare
| Models | Max. Lifting Capacity | Max. Boom Length | Max. Lifting Height |
|---|---|---|---|
| STC1000T6 | 100 T | 60 m | 87 m |
| STC1100T6 Brazil | 110 T | 60 m | 87 m |
| STC1100T7-1 | 110 T | 75.5 m | 102.5 m |
| STC1200T7 Brazil | 120 T | 68.2 m | 95.2 m |
| STC1600T7 | 160 T | 75.5 m | 102.5 m |
